Salehi Machines

Cutting & Marking Laser System


Product

Features
  • Capability of vectorizing.
  • 3D engraving.
  • Ability to engrave multi-layer patterns.
  • Smooth surface finish according to global standards.
  • Equipped with a piece locator camera.
  • Equipped with an infrared height sensor.
  • Equipped with a professional piece locator camera.
  • High-speed and high-precision scanning head (German LabScan).
  • Engraving and creating various color spectrums (12 colors).
  • Ability to perform cutting and engraving operations simultaneously.
  • Equipped with a silicone suction system (blue) to minimize gold waste.

Category: Laser Machines

Description

Engraving and cutting machine, Model FINECUT, is the special device for cutting metals. With a high power, a precise cutting line, small size of width ( 0.01 mm ) and a high speed, these machines help you to cut metal sheets with a high function and low waste. The new generation of this machine could make the diameter of the laser light of the brand way different and distinguished from other brands in an amazing way by using of SPI laser generators with MOPA technology and high capability.

Cutting & Marking Laser System

The high speed of cutting, high quality of the surface and low usage of energy are some of the unique features of this machine. These series of machines are presented in 70W, 100W and 120W which for an example, the 70W could cut a metal sheet of 1/2 mm. The machine is capable of cutting automatically by using pneumatic clamps which allows to work in high quantities without the need of an operator. Z axis works automatically and by using of combination of more than 10 smart programs, makes the application of the machine so easy.

Specification

Laser power

40-50-60-70-80-100 W(Universal)

Light source power

220 V/10%/50Hz or 110V/10%/60Hz

Laser type

Fiber

Engraving speed

0 - 1000 mm/min

Supporting software

CorelDraw - AutoCad

Dimensions

10*10 , 36*36

  • Capability of vectorizing.
  • 3D engraving.
  • Ability to engrave multi-layer patterns.
  • Smooth surface finish according to global standards.
  • Equipped with a piece locator camera.
  • Equipped with an infrared height sensor.
  • Equipped with a professional piece locator camera.
  • High-speed and high-precision scanning head (German LabScan).
  • Engraving and creating various color spectrums (12 colors).
  • Ability to perform cutting and engraving operations simultaneously.
  • Equipped with a silicone suction system (blue) to minimize gold waste.

Engraving and cutting machine, Model FINECUT, is the special device for cutting metals. With a high power, a precise cutting line, small size of width ( 0.01 mm ) and a high speed, these machines help you to cut metal sheets with a high function and low waste. The new generation of this machine could make the diameter of the laser light of the brand way different and distinguished from other brands in an amazing way by using of SPI laser generators with MOPA technology and high capability.

Cutting & Marking Laser System

The high speed of cutting, high quality of the surface and low usage of energy are some of the unique features of this machine. These series of machines are presented in 70W, 100W and 120W which for an example, the 70W could cut a metal sheet of 1/2 mm. The machine is capable of cutting automatically by using pneumatic clamps which allows to work in high quantities without the need of an operator. Z axis works automatically and by using of combination of more than 10 smart programs, makes the application of the machine so easy.

Laser power

40-50-60-70-80-100 W(Universal)

Light source power

220 V/10%/50Hz or 110V/10%/60Hz

Laser type

Fiber

Engraving speed

0 - 1000 mm/min

Supporting software

CorelDraw - AutoCad

Dimensions

10*10 , 36*36
